RS-600e

Home/RS-600e

Specifications

General
  • Dimensions
 3,605(L) x 1,353(W) x 1,490(H) mm
  • Weight
 Approx. 1,600 kg
  • No. of heating zone
 Top 6 & bottom 6
  • No. of cooling zone
 1 (Inside)
  • Effective heating length
 2,330 mm
  • Cooling zone length
 400 mm

Heating system
  • Temperature control method
 PID closed loop control + SSR drive
  • Range of temperature set-up
 Room temp. - 300°C
  • Hot air velocity adjustable range
 20 - 50 Hz
  • Max. temperature setting difference between preheating & soldering zones
 70°C
  • Max. temperature setting difference between each preheating zone
 40°C
  • Max. temperature setting difference between each soldering zone
 40°C
  • Precision of temperature control
 ± 1°C
  • Temperature deviation tolerance on PCB
 ± 1.5°C

Conveyor system
  • Clearance
 Top 30 mm & bottom 25 mm
  • PCB width range
 50 – 460 mm
  • Conveying speed range
 300 – 2,000 mm/min
  • PCB transmission mode
 Rails & mesh
  • Conveying height
 900 ± 20 mm
  • Fixed rail side
 Front (Option: Rear)
  • PCB conveying direction
 Left to right (Option: Right to left)
  • Conveyor width adjusting method
 Motorized
  • Upper chamber open method
 Motorized
  • Automatic lubrication
 Standard

Utilities
  • Total power
 42 kW
  • Start-up power
 26 kW
  • Normal power consumption
 Approx. 8 kW
  • Warm-up time
 Approx. 25 mins
  • Exhaust volume
 10 m3/min x 2 pcs


* JTU reserves the right to make any changes concerning design or specification without notice to customers due to continuous improvement.

Mechanical drawing
