HCZ-400

Home/HCZ-400

Specifications

General
  • Dimensions
 2,365(L) x 2,000(W) x 2,050(H) mm
  • Weight
 Approx. 1,800 kg
  • Max. PCB size
 450(L) x 400(W) mm
  • Object weight
 Max. 2 kg per level
  • Power supply
 3 phase, 380 V AC, 50/60 Hz
Heating system
  • Temperature control method
 PID closed loop control + SSR drive
  • Range of temperature set-up
 Room temp. - 200°C
  • Heating configuration
 4 * 2 = 8 heating modules
  • Heater power
 8 * 6 kW = 48 kW
  • Temperature control precision
 ± 1°C
  • Temperature deviation
 ≤ ± 2°C
Conveyor system
  • Conveyor direction
 Left to right (Option: Right to left)
  • Pitch between levels
 25.4 mm
  • Board or carrier edge clearance
 5 mm
  • Total level
 60 (30 up, 30 down)
  • Conveying height
 900 ± 30 mm
  • Shortest indexing time
 13 sec
  • Elevator motor
 Stepper motor
  • Conveyor width adjusting method
 Motorized

* JTU reserves the right to make any changes concerning design or specification without notice to customers due to continuous improvement.
