AR-1003D

Home/AR-1003D

Specifications

General
  • Dimensions
 6,520(L) x 1,656(W) x 1,560(H) mm
  • Weight
 Approx. 2,800 kg
  • No. of heating zone
 Top 10 & bottom 10
  • No. of cooling zone
 Top 3 & bottom 3
  • Effective heating length
 3,950 mm
  • Cooling zone length
 1,200 mm
Heating system
  • Temperature control method
 PID closed loop control + SSR drive
  • Range of temperature set-up
 Room temp. - 300°C
  • Max. temperature setting difference between preheating & soldering zones
 80°C
  • Max. temperature setting difference between each preheating zone
 40°C
  • Max. temperature setting difference between each soldering zone
 40°C
  • Precision of temperature control
 ± 1°C
  • Temperature deviation tolerance on PCB
 ± 1.5°C
Conveyor system
  • Clearance
 Top 30 mm & bottom 30 mm
  • PCB width range
 50 – 270 mm x 2 lanes
  • Conveying speed range
 300 – 2,000 mm/min
  • PCB transmission mode
 Rails & mesh
  • Conveying height
 900 ± 20 mm
  • Fixed rail side
 1st & 4th rails (Option: Others)
  • Distance between1st & 4th rails
  686 mm
  • PCB conveying direction
 Left to right (Option: Right to left)
  • Conveyor width adjusting method
 Automatic
  • Automatic lubrication
 Standard
Utilities
  • Total power
 100 kW
  • Start-up power
 36 kW
  • Normal power consumption
 Approx. 12 kW
  • Warm-up time
 Approx. 30 mins
  • Exhaust volume
 10 m3/min x 2 pcs

* JTU reserves the right to make any changes concerning design or specification without notice to customers due to continuous improvement.
